TRUCK MOUNT SERIES Stationary Gas Air Compressors
Model 13GR30HK30 (shown here) produces 23.0 CFM @ 175 PSI and comes with a 389 cc (GX390) Electric-Start Honda engine that features automatic idle-down, for increased fuel efficiency, and an atmospheric unloading system to prevent oil consumption. Mounted on a 30 gallon ASME tank, this unit is often used on service vehicles or in agricultural applications.
ABOUT THE PUMP
- Two-Stage
- Cast-Iron Cylinders
- Aluminum Head and Crankcase for Faster Heat Dissipation
- Ball Bearings
- Splash Lubricated
- Bearing Inserts on Connecting Rods
- Swedish Lammelar Reed Valves
- Oil Sight Gauge
- Low RPMs to Ensure Long Life and Trouble-Free Performance
ABOUT THE ENGINE
- 389 cc (13 HP) Honda OHV Engine
- Electric Start with Recoil Back-Up
- Alternator
- Low Oil Shutdown
STANDARD EQUIPMENT
- Automatic Engine Idle Control for Economy and Long Service Life
- Schmidt Belt Tightening Device
- Automatic Pilot Valve Operation
- Pressure Gauge 0-300 in 5 lb. Graduations
- Safety Relief Valve ASME Approved
- Long Lasting Flexible Brass Discharge Hose
- Totally Enclosed Steel Belt Guard
Specifications
| Horse Power | 163 cc (5 HP) to 688 cc (20 HP) |
| CFM Displaced | 13.1 - 41.0 CFM |
| CFM Delivered | 8.7 - 33.7 CFM |
| Lubrication Type | Splash Lubrication |
| Reed Valve System | Yes (Standard) |
| Number of Cylinders | 2 - 4 |
| Country Of Origin | Compressor Origin.pdf |
Buy Online Now
We invite you to shop online with confidence at the following Rolair dealers. Each Rolair online dealer is verified to provide a secure shopping experience, offering the most complete selection of Rolair compressors and accessories.
Acme Tools
https://www.acmetools.com
Air Compressors Direct
https://www.aircompressorsdirect.com
Ace Tool
https://www.acetool.com
Diamond Tool Store
https://www.diamondtoolstore.comADDITIONAL MODELS
| Model # | HP | Phase | Tank Size | Motor RPM | CFM Displaced | CFM Delivered | Length | Width | Height | Approx. Shipping Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| 5GR30HK17 | 5 | N/A | 30 Gallons | N/A | 13.1 @ 100 PSI | 8.7 @ 100 PSI | 42" | 22" | 38" | 250 lb. |
| 13GR30HK30 | 13 | N/A | 30 Gallons | N/A | 29.5 @ 175 PSI | 23.0 @ 175 PSI | 42" | 22" | 48" | 395 lb. |
| 13GR60HK30 | 13 | N/A | 60 Gallons | N/A | 29.5 @ 175 PSI | 23.0 @ 175 PSI | 52" | 26" | 52" | 495 lb. |
| 13GRBMHK30 | 13 | N/A | Base Mount | N/A | 29.5 @ 175 PSI | 23.0 @ 175 PSI | 38" | 20" | 32" | 295 lb. |
| 20GRBMHK60 | 20 | N/A | Base Mount | N/A | 41.0 @ 175 PSI | 33.7 @ 175 PSI | 53" | 29" | 32" | 435 lb. |
| 20GR60HK60 | 20 | N/A | 60 Gallons | N/A | 41.0 @ 175 PSI | 33.7 @ 175 PSI | 64" | 30" | 50" | 585 lb. |
